The HMC series tracked mobile crushers are widely used in aggregates production and recycling worldwide. Thanks to their track-mounted design, HAMAC machines are easy to move on-site and transport between locations. Often referred to as "mobile crushing plants," they maximize productivity, reduce operating costs, enhance safety, and lower environmental impact. Their components are similar to stationary crushers but offer full mobility, even on steep slopes with a 1:10 incline. This makes them ideal for versatile and efficient crushing operations.
Processing capacity : 150-495（T/H）
Main machine power : 0.6-1（KW）
Most types of rocks, metallic ores, and other minerals, such as limestone, granite, marble, basalt, iron ore, copper ore, and more.
Popular in aggregates, highway construction, railway construction, airport building, and several other industries.
Tracked crusher and screens are used widely in the world for different projects as below:
1. Widely used in mines, coal mines, recycling of garbage and construction waste, earthwork engineering, urban infrastructure, roads or construction sites.
2. Processing of topsoil and other materials; separation of viscous aggregate; construction and blasting industries; screening after crushing; quarrying industry.
Discover the benefits of the 200t/h soft rock portable crushing plant. Learn how its mobile design enhances flexibility, increases...
Explore the essential equipment and features of a lead-zinc ore crushing plant, focusing on operational efficiency and investment ...
The 400-450t/h soft rock crushing plant is a high-capacity solution for processing soft rock materials like limestone, gypsum, and...
Explore the essential equipment and features of a manganese ore crushing plant, focusing on operational efficiency and investment ...
Explore the essential equipment and features of a marble crushing plant, focusing on operational efficiency and investment return.
Explore the essential equipment and features of a riverstone crushing plant, focusing on operational efficiency and investment ret...
This 150-180tph stationary crushing and screening plant was installed in 2009. In the spring festival holiday, this client called ...
This mobile jaw crusher was exported to Oman in 2010. It is our biggest mobile jaw crusher. This client only process the big stone...
This mobile crushing and screening plant was exported to Guinea in 2012. It is a complete mobile crusher and vibrating screens on ...
This 250tph stationary aggregate crushing and screening plant as delivered to South Sudan in 2011. It is a project which was inves...
This 150tph stationary crushing and screening plant was installed in 2011 in Iraq. It was installed in a mountain valley. Up to no...
This mobile crushing and screening plant was exported to Algeria in 2013. It is a complete mobile crusher and vibrating screens on...
| Model | MC200HRSE | MC300HRE | MC300HRSE | MC400HRSE |
|---|---|---|---|---|
| Feeder | ||||
| Volume(m³) | 6.5 | 6.5 | 6.5 | 6.5 |
| Feeding height(mm) | 2900 | 2870 | 2900 | 2560 |
| Maximum feed size(mm) | 185 | 225 | 225 | 275 |
| Feeding capacity(t/h) | 400 | 500 | 500 | 700 |
| Crusher | ||||
| Host model | HPC200 | HPC300 | HPC300 | HPC400 |
| Return screen length×width(mm) | 1740x5000 | 1740x5000 | 1740x5000 | 1800x5000 |
| Number of layers | 1 | 1 | 1 | 1 |
| Closed side setting(mm) | 20-32 | 6-45 | 6-45 | 22-51 |
| Conveyor | ||||
| Main conveyor belt width (mm) | 1200 | 1200 | 1200 | 1200 |
| Transfer conveyor belt width (mm) | 500 | 500 | 500 | 500 |
| Re-circulation conveyor belt width (mm) | 500 | 500 | 500 | 500 |
| Under screen conveyor belt width (mm) | 1000 | 1000 | 1000 | 1000 |
| Stack height （mm） | 2840 | 2840 | 2840 | 2840 |
| Power Unit | ||||
| Generator power (kW) | 400KW | 500KW | 500KW | 600KW |
| Diesel tank capacity | 1000L | 1200L | 1000L | 1500L |
| Hydraulic tank capacity | 300L | 300L | 300L | 300L |
| Technical Data | ||||
| Total power(kw) | 237.7 | 340.3 | 331.2 | 396.2 |
| Host power(kw) | 160 | 250 | 250 | 315 |
| Processing capacity(t/h) | 150-230 | 150-430 | 150-430 | 270-550 |
| Track speed(km/h) | 0.6-1 | 0.6-1 | 0.6-1 | 0.6-1 |
| Total weight(t) | 57 | 66 | 61 | 76 |
| Transport dimension(mm) | 18903×3880×3886 | 20105x3834x3979 | 18903×3880×3886 | 19957×3918×3980 |
